The Weighty Issue of Two-Handed Greatswords



Двуручный меч в реальности и фантастике | Основные стойки, удары и мулине | Защиты и комбинации | Античный двуручный меч - ромфея | Правила испанского двуручного меча | Цвайхендеры - зачем они все-таки были нужны? | The Weighty Issue of Two-Handed Greatswords



By J. Clements

"never overlay thy selfe with a heavy weapon, for nimblenesse of bodie, and nimblenesse of weapon are two chief helpes for thy advantage"

Joseph Swetnam, 1617

The Schoole of the Noble and Worthy Science of Defence

Popular media, fantasy games, and uninformed historians frequently give the impression that these immense weapons were awkward, unwieldy and ponderously heavy. The facts confirm an entirely different understanding.

Identification - Definition of the Two-Handed Great Sword

To understand what we are discussing it is important to first have a working definition. The respected work, Swords and Hilt Weapons, offers this description of the weapon:

"The two-handed sword was a specialized and effective infantry weapon, and was recognized as such in the fifteenth and sixteenth centuries. Although large, measuring 60-70 in/150-175 cm overall, it was not as hefty as it looked, weighing something of the order of 5-8 lbs/2.3-3.6 kg. In the hands of the Swiss and German infantrymen it was lethal, and its use was considered as special skill, often meriting extra pay. Fifteenth-century examples usually have an expanded cruciform hilt, sometimes with side rings on one or both sides of the quillon block. This was the form which remained dominant in Italy during the sixteenth century, but in Germany a more flamboyant form developed. Two-handed swords typically have a generous ricasso to allow the blade to be safely gripped below the quillons and thus wielded more effectively at close quarters. Triangular or pointed projections, known as flukes, were added at the base of the ricasso to defend the hand." (Coe et al, p. 48)

In contrast to longswords, technically, true two-handed swords (epee`s a deux main) or "two-handers" were actually Renaissance, not Medieval weapons. They are really those specialized forms of the later 1500-1600s, such as the Swiss/German Dopplehänder ("double-hander") or Bidenhänder ("both-hander"). The popular names Zweihander / Zweyhander are actually relatively modern not historical terms. English ones were sometimes referred to as "slaughter-swords" after the German, Schlachterschwerter ("battle swords"). While used similarly to longswords, and even employed in some duels, they were not identical in handling or performance. No major historical teachings detailing fencing with these specific weapons are known. These weapons were used primarily for fighting among pike-squares where they would hack paths through knocking aside poles, possibly even lobbing the ends off opposing halberds and pikes then slashing and stabbing among the ranks. Wielded by the largest and most impressive soldiers (Doppelsoldners, who received double pay), they were also used to guard banners and castle walls. The Italian humanist historian Paulus Jovius writing in the early 1500s also described the two-hand great sword as being used by Swiss soldiers to chop the shafts of pikes at the battle of Fornovo in 1495.

Many of these weapons have compound-hilts with side-rings and enlarged cross-guards of up to 12 inches. Most have small, pointed lugs or flanges protruding from their blades 4-8 inches below their guard. These parrierhaken or "parrying hooks" act almost as a secondary guard for the ricasso to catch and bind other weapons or prevent them from sliding down into the hands. They make up for the weapon`s slowness on the defence and can allow another blade to be momentarily trapped or bound up. They can also be used to strike with. Certain wave or flame-bladed two-handed swords have come to be known by collectors as flamberges, although they are more appropriately known as flammards or flambards (the German, Flammenschwert). The wave-blade form is visually striking but really no more effective in its cutting than a straight one. There were also huge two-handed blades known as "bearing-swords" or "parade-swords" (Paratschwert), weighing up to 10 or even 15 pounds and which were intended only for carrying in ceremonial processions and parades.

Dr. Hans-Peter Hils in his 1985 dissertation on the work of the great 14th century master Johannes Liechtenauer noted that since the 19th century many arms museum collections typically feature immense parade or bearing greatswords as if they were actual combat weapons ignoring the fact they are not only blunt edged, but of impractical size and weight as well as poorly balanced for effective use. (Hils, p. 269-286). Though never intended for actual fighting, examples of such ponderous specimens are still occasionally cited incorrectly as having been actual combat weapons..

One source tells us that among 16th century armies the adoption of the two-handers was very limited and in comparison with the pike or the halberd did not play a meaningful role. «In the infantry unit, the German and Swiss Landsknechts positioned the Doppelsöldner (Soldiers who received double pay for wielding the two-handers) in the front ranks for a long time to strike down the opposing pikes and to hack out peaches into which one`s own soldiers could penetrate. However it would become unusable, as soon as the opposing forces collided with one another, and there would be increased pressure from the back ranks onto the front ranks, which created a thick melee.» Thus, «sometime around the middle of the 16th century it (the two-hander) disappeared from war and mutated into a form of guard and ceremonial weapon with a symbolic character.» (Kamniker and Krenn, p. 130).

As one writer says of the weapon, "Among the smaller countries where mercenary bands were likely to develop---the Low Countries, the Italian city states, and the free cities and states of the German lands---the Swiss became premier two-handed swordsmen for hire from the 14th century until well into the 16th century. The two-handed sword and the multipurpose polearm, called the halberd, were familiar Swiss trademarks. The Swiss and Germans made their own two-handed swords. The Italians made a basic two-hander that they exported throughout Europe. Two-handed swordsmen were perimeter shock troops, trained to lay into approaching knights or infantry and peak their stride. By the end of the 15th century, however, the Swiss had turned almost exclusively to the 17- to 18-foot pike as their weapon of choice, becoming the premier pikemen of Europe. The two-handed sword was considered incompatible with the pike and was actually outlawed as a frontline weapon by many confederation members--though the Swiss kept making them. The two-hander remained a popular weapon among many other European mercenaries, in Italy and particularly in Germany." (William J. McPeak. "For a Swordsmen with Muscle as Well as Skill, Two Hands Could be Better Than One." Military Historyy, Oct 2001, Vol. 18. Issue 4, p 24).

Answering the Weight Question - how much did the actual historic weapons really weigh?

Nothing answers the question of genuine weight better than sample evidence of actual historical specimens. Sword collector and author Dr. Lee Jones possesses a very fine specimen of a 16th century German two-handed great sword, that this author had the privilege of exercising outdoors with, had length in excess of five feet and a weight of 7.9 pounds (3490g), but handled easily with superb balance. Curator of arms for the Hungarian Military History Museum in Budapest, László Töl, describes a very fine specimen of another 16th century German two-handed great sword of 53.4 inches length, which this author also had the privilege of examining, as weighing only a little over 8 pounds. Again, the piece`s size and weight betrayed a functional and well-balanced weapon. László Töl adds: "The full length of the sword is 1808 mm, the full length of the blade is 1355 mm, the edge of the blade is 936 mm long, the length of the hilt is 306 mm, and the diameter of the cross-guard is 502 mm. The width of the blade is 46 mm, and its thickness is 7.5 mm. The "neck" of the blade is 8.6 mm thick and 32 mm wide. The centre of gravity is 616 mm from the pommel. The sword weighs 3650g. The blade`s cross-section is rhomboid in shape."

A 15th century two-handed Federschwertt (practice sword) of 51.5 inches in length now at the Swiss National Landesmuseum weighs in at only 3.12lbs (1.415kg). Another warsword there of 48 inches in length weighs 4.63lbs (2.10kg), and an acutely tapered one of a length of 46.7 inches weighs in at only 3.018lbs (1.369kg). By comparison, a single-hand sword of 38-inches in the same collection weighed 3.28lbs (1.495kg).

The author has handled two-handed greatswords at the pitish Royal Armouries in Leeds that were distinctly identifiable as fighting weapons. The current curator of European edged weapons, Robert C. Woosnam-Savage, at the Royal Armouries writes:

"The fighting two-handed sword, weighed (on average) between 5-7 lbs. I give the following three examples, randomly chosen from our own collections, which I hope are adequate to make the point:

Two-handed sword, German, c.1550 (IX.926). Weight: 7 lb 6oz.

Two-handed sword, German, dated 1529 (IX.991). Weight: 5 lb 1oz.

Two-handed sword, Scottish, mid 16th century, (IX.926). Weight: 5 lb 10oz.

Arms authority, David Edge, former head curator and current conservator of the famed Wallace Collection museum in London, similarly states for us:

"I very recently had occasion to handle a couple of similar-sized hand-and-a-half 16th-century "heading" swords in the [Wallace] Collection...one undoubtedly genuine (#A721) and one now thought to be a Victorian fake (A723), albeit not described as such in the 1962 [Wallace Collection] catalogue. The two swords handled completely and dramatically differently...on checking their weights the genuine one weighed 3 lbs. 12 oz., and felt like it could take a head off with ease, while the fake weighed in at an unwieldy 5lbs 3 oz. and to wield felt more like an iron bar intended to bludgeon the unfortunate prisoner to death! Clearly making replica swords too heavy is not the sole prerogative of modern manufacturers...Victorian copyists appear sometimes to have fallen into the same trap! It is interesting to compare these weights with that of a double-handed fighting sword of similar date...for example, our Landsknecht double-hander #A470, the one with a wavy blade. This (a much larger sword all round) still only weighs a mere 7 lbs. 4 oz."

"Original weapons are indeed far lighter than most people realize ...3 lbs for an "average" late-medieval cross-hilt sword, say, and 7-8 lbs for a Landsknecht two-handed sword, to give just a couple of examples from weapons in this collection. Processional two-handed swords are usually heavier, true, but rarely more than 10 lbs. The heaviest and most enormous sword in our entire Armoury only weighs 14 lbs and was probably ceremonial."

ARMA consultant Henrik Andersson of the Livrustkammaren, Swedish Royal Armoury of Stockholm, provides a table with the following measurements on two-handed and greatswords in the collection there. The author and his colleagues have handled several of these pieces:

Two-handed sword. No: LRK 13639.

  • Swedish, c1658
  • Length: 1010 mm (39.7 inches)
  • Blade: 862 mm (33.9 inches)
  • Weight: 1735 g (3.47 pounds)

Ceremonial Two-handed sword. No: LRK 5666.

  • Swedish, c1658.
  • Length: 1025 mm (40.3 inches)
  • Blade: 933 mm (36.7 inches)
  • Weight: 1590 g (3.18 pounds)

Two-handed sword. No: LRK 12959.

  • Solingen, Early 17th century.
  • Length: 1350 mm (56.2 inches)
  • Blade: 961 mm (37.8 inches)
  • Weight: 3010 g (6.2 pounds)

Two-handed sword. No: LRK 16660.

  • German, 17th century.
  • Length: 1428 mm ( inches)
  • Blade: 1048 mm ( inches)
  • Weight: 2730 g (5.46 pounds)

Two-handed sword. No: LRK 16662.

  • German, Late 16th century.
  • Length: 1790 mm (70.4 inches)
  • Blade: 1250 mm (49.2 inches)
  • Weight: 4630 g (9.26 pounds)

One-and -a-half-handed sword. No: LRK 10972.

  • Southern German, c1550.
  • Length: 1252 mm ( inches)
  • Blade: 1019 mm ( inches)
  • Weight: 1500 g (3 pounds)

Two-handed sword. No: LRK 12947.

  • German, 16th century.
  • Length: 1185 mm (46.6 inches)
  • Blade: 954 mm (37.5 inches)
  • Weight: 1240 g (2.48 pounds)

Two-handed sword. No: LRK 12667.

  • German, 16th century.
  • Length: 1225 mm (48.2 inches)
  • Blade: 904 mm (35.5 inches)
  • Weight: 1310 g (2.62 pounds)

One-and -a-half-handed sword. No: LRK 12913.

  • Probably German, c. 1350
  • Length: 1170 mm (46 inches)
  • Blade: 829 mm (32.6 inches)
  • Weight: 1280 g (2.56 pounds)

Two-handed sword. No: LRK 12716.

  • German, c1500.
  • Length: 1340 mm (52.7 inches)
  • Blade: 955 mm (37.6 inches)
  • Weight: 1390 gr (3 lbs)

One-and -a-half-handed sword. No: LRK 12711.

  • German, c1475-1525.
  • Length: 1153 mm (45.3 inches)
  • Blade: 932 mm (36.6 inches)
  • Weight: 1320 g (2.9 lbs)

Ceremonial Two-handed sword. No: LRK 6362.

  • German (probably Passau) c1600.
  • Length: 1275 mm (50.1 inches)
  • Blade: 1000 mm (39.37inches)
  • Weight: 2330 g (5.1 lbs)

Ceremonial Two-handed sword. No: LRK 16370.

  • German. Late 16th century.
  • Length: 1422 mm (55.9 inches)
  • Blade 1029 mm (40.5 inches)
  • Weight: 2700 g (5.9 lbs)

Ceremonial Two-handed sword. No: LRK 6956.

  • punswick type. German. Late 16th century.
  • Length: 1893 mm (74.5 inches)
  • Blade: 1313 mm (51.7 inches)
  • Weight: 4830 gr (10.6 lbs)

Ceremonial Two-handed sword. No: LRK 6941.

  • punswick type. German. Late 16th century.
  • Length: 1817 mm (71.5 inches)
  • Blade: 1240 mm (48.8 inches)
  • Weight: 3970 g (8.75 lbs)

Ceremonial Two-handed sword. No: LRK 16371.

  • punswick type. Munich, c1550-1575.
  • Length: 1643 mm (64.7 inches)
  • Blade: 964 mm (37.9 inches)
  • Weight: 3500 g (7.7 lbs)

Two-handed sword. No: LRK 12706.

  • German. Late 15th century.
  • Length: 1473 mm (58 inches)
  • Blade: 1066 mm (41.9 inches)
  • Weight: 2720 g (5.9 lbs)

Two-handed sword. No: LRK 12715.

  • German, c1475-1525.
  • Length: 1382 mm (54.4 inches)
  • Blade: 1055 mm (41.5 inches)
  • Weight: 1550 g (3.4 lbs)

Two-handed sword. No: LRK 5480.

  • Germany, 15th century.
  • Length: 1375 mm (54.2 inches)
  • Blade: 920 mm (36.2 inches)
  • Weight: 1600 g (3.5 lbs)

Note that unlike ceremonial specimens, none of the fighting weapons exceeded 4 pounds and the heaviest ceremonial was less than 11. The catlog of the famous arsenal in Graz, Austria, contains similar weights for its two-handed great sword specimens.

Historical fencing researcher and author, Grzegorz Zabinski, observes, "It can be assumed that the two-handed infantry swords were a culminating point of one of the directions of the evolution of swords, that aimed to increase their efficiency against plate by means of increasing their dimensions and weight, and, quite naturally, their impact." Zabinski offers sample data for a range of two-handed infantry swords from the end of the 15th and the beginning of the 16th centuries at the excellent collection of such weapons housed in the State Art Collection at the Royal Castle of Wawel, Krakow, Poland:

  • Two-Handed Infantry Sword with parrying-hooks. No. 4434. Late 15th - early 16th century. Total length 167 cm (65.7 inches), total weight 3 kg (6 pounds), blade length 117 cm, hilt length 50 cm, crosspiece length 34 cm. Blade`s width at the shoulder 43 mm, at the parrying-hooks 36 mm, behind the parrying-hooks 50 mm, at the point 33 mm. Blade`s thickness at the shoulder 11 mm.
  • Two-Handed Infantry Sword with parrying-hooks. No. 4435. Early 16th century. Total length 158 cm (62 inches), total weight 3.10 kg (6.2 pounds), blade length 114.5 cm, hilt length 44 cm, crosspiece length 41.5 cm. Blade`s width at the shoulder 33 mm, width at the point 58 mm. Blade`s thickness at the shoulder 9 mm.
  • Two-Handed Infantry Sword with side-rings. No. 4437.Early 16th century. Total length 163 cm (64 inches), total weight 3.25 kg (6.5 pounds), blade length 125 cm, hilt length 38 cm, crosspiece length 38 cm. Blade`s width at the shoulder 53mm, at the point 30 mm. Blade`s thickness at the shoulder 8 mm, at the point 2 mm.
  • Two-Handed Infantry Swordwith parrying-hooks. No. 4440. Late 15th - early 16th century. Total length 167 cm (65.7 inches), total weight 3 kg(6 pounds), blade length 122.2 cm (48 inches), hilt length 44.5 cm, crosspiece length 39 cm. Blade`s width at the shoulder 47 mm, at the point 26 mm. Blade`s thickness at the shoulder 7 mm, at the point 2 mm. The parrying-hooks: total length 13.7 cm, pointed, width at the shoulder 1.5 cm.
  • Two-Handed Infantry Sword.National Museum Wroclaw. No. IX-780. Late 15th - early 16th century. Total length 148 cm (58 inches), total weight 2 kg (4 pounds), blade length 107.5 cm, hilt length 39.8 cm, crosspiece length 31.3 cm. Blade`s width at the shoulder 38 mm, at the point 33 mm. Blade`s thickness at the shoulder 10 mm, at the point 4 mm.
  • Two-Handed Infantry Sword with parrying-hooks. National Museum Wroclaw, No. IX-784. Early 16th century. Total length 164 cm (64 inches), total weight 2 kg (4 pounds), blade length 146.8 cm, hilt length 45.8 cm, crosspiece length 39.4 cm. Blade`s width at the shoulder 35 mm. Blade`s thickness 10 mm at the shoulder, 2.5 mm at the point. The pommel`s height (base included) 5.4 cm, base`s height 5 mm, pommel`s diameter 5.4 cm.

Note that of the samples here the heaviest is less than 7 and a half pounds and one particularly large weapon of 58 inches weighs no more than 4 pounds.

A practical explanation for the futility of especially heavy weapons is that they are slow. In physics terms, doubling the mass of a weapon can provide twice the strike energy, but doubling the velocity of a strike provides four times the energy.

Below is a table of measurements from 69 two-handed great swords from the 16th century in the famed Austrian arsenal of Graz (K. Kamniker and P. Krenn, p. 139-152). Note that the average weight is less than 8 pounds at an average length of 67 inches. The weapons in the collection range up to 5 pounds difference in their weight. The lightest weapon, a slender blade, is just over than 3.3 pounds (at roughly 57 inches long) while the heaviest, a large and elaborately hilted piece, is no more than 13 pounds (at about 78 inches a long):

A 40-Pound Sword?

By C. Jarko

One of the most outrageous (and wildly incorrect) statements made about Medieval swords is that they were heavy and weighed as much as 40 pounds. While the fact that this statement even came once from a respected scholar and expert on Medieval warfare is surprising, it`s not at all an uncommon claim. Let`s take a look at just how large a sword would have to be to weigh that much or anywhere close to it.

Simple Science (with a little algepa thrown in): How do we know Medieval swords weren`t 40 pounds (or for that matter, even 15 or 20 pounds)? The answer is density. Density is a way of expressing how much an object (of a certain size and of a given material) weighs. The size of the object is expressed in terms of its volume. Volume is the size of an object as measured by its length, width and thickness (or height) and is expressed in cubic inches. Written as a mathematical equation, it looks like this:

V = L x W x H.

One cubic inch is one inch long by one inch wide by one inch thick.

For the purpose of this discussion, we can use a simple three-dimensional rectangle to represent our sword. Let`s pick a typical longsword with an overall length of 48 inches and a general width of 2 inches (the widest part of the blade). We`ll get to the height later.

Swords were made of carbon steel, which has a known density of roughly 0.284 pounds per cubic inch (lbs/per cubic inch). If we know how much weight we have (in this case "40" pounds), we can figure out how many cubic inches the object would have:

40 pounds divided by 0.284 (the density of steel) = 140.85 cubic inches (the volume or "V" of a 40 pound sword).

Our sword is 48 inches long, 2 inches wide and "H" inches thick, thus: V = 48 x 2 x H. Using our volume of 140.85, we can solve for H for which we get:

140.85 = 48 x 2 x H

140.85 = 96 x H

H= 1.47 inches (140.85 divided by 96)

This means our steel sword is 48 inches long, 2 inches wide and 1.47 inches thick along its entire length. This would definitely be a blunt object and not a sharp cutting instrument like a sword.

Just for fun, let`s see what we get when we say a sword (again 48 inches long and 2 inches wide) weighs 15 pounds or 10 pounds:

15 pounds divided by 0.284 (the density of steel) = 52.82 cubic inches (the volume "V" of a 15 pound sword).

Using our volume of 52.82, we can solve for H:

52.82 = 48 x 2 x H

52.82 = 96 x H

H = 0.55 inches (52.82 divided by 96)

That`s over half an inch thick, still a blunt object. Let`s try one more time for 10 pounds.

10 pounds divided by 0.284 (the density of steel) = 35.21 cubic inches (the volume "V" of a 15 pound sword).

Again, we can solve for H:

35.21 = 48 x 2 x H

35.21 = 96 x H

H = 0.37 inches

That`s almost three eighths of an inch thick. If you look at three eighths of an inch on a ruler, you`ll see we are now starting to get "sword-like" but we`re still not there.

If we do the math using the thickness of a real sword (say an average 1/8th inch thick across a roughly 48" by 2" rectangle) it turns out such it weighs a reasonable 3.408 pounds. Which, when you take into account things like differential cross-section, distal taper, edge bevel and overall taper of the blade geometry, as well as the weight of the pommel and cross, then an average weight of 2.5 - 3.5 pounds works out just about right. So, the next time

When someone says "a longsword weighs 15 pounds", you can reply, "Oh, like this?" as you hand them 15 pounds of a half-inch thick steel slab four feet long and two inches wide. There`s nothing like holding the truth in your hands. If there were really battle swords that actually weighed 40 pounds, or even just 15 or 20 pounds, then where are they? Why don`t we have a single historical example as proof? It would be such an easy thing to prove. So, if you have a modern made sword which you bought and it weighs far more than the real life working versions of history, no matter what the manufacture claims, that sword is just not made correctly.

When we use the mathematical proof, we need to understand that there are variables which we aren`t taking into account here, but this line of argument works well enough to debunk the more outrageous claims about sword weight. The next time you`re arguing with someone who refuses to budge off their claim that swords were very heavy and unwieldy, you can tell them: "Hey, you do the math!"

An ordinary exercise bar (available at most large sporting goods stores) is an excellent way to demonstrate how real swords were not "heavy." These 50" poles come in 9, 12, and 14 pound versions and comparing the heft of such weight to a sword blade makes it very clear how absurd a weapon of such mass would be..

Sword Number Length
in cm
Weight
in kg
Length
in inches
Weight in pounds
1 169 3.76 66.5 8.2
2 168 3.44 66.1 7.5
3 156 3.08 61.4 6.7
4 169 3.13 66.5 6.9
5 172 3.5 67.7 7.7
6 180.5 4.35 71.0 9.5
7 184 3.66 72.4 8.0
8 170.5 3.6 67.1 7.9
9 195.5 5.92 76.9 13.0
10 197 5.4 77.5 11.9
11 186.5 4.33 73.4 9.5
12 180.5 4.28 71.0 9.4
13 178 3.51 70.0 7.7
14 182 3.75 71.6 8.2
15 186 3.93 73.2 8.6
16 199 5.42 78.3 11.9
17 187.5 4.7 73.8 10.3
18 175.5 3.64 69.0 8.0
19 162 3.28 63.7 7.2
20 168.5 2.45 66.3 5.4
21 170.5 3.37 67.1 7.4
22 158.5 2.88 62.4 6.3
23 170.5 3.67 67.1 8.0
24 164.5 3.8 64.7 8.3
25 158 3.11 62.2 6.8
26 168.5 3.39 66.3 7.41
27 173.5 3.73 68.3 8.2
28 170.5 3.51 67.1 7.7
29 176.5 3.63 69.4 8.0
30 176 3.77 69.2 8.3
31 174.5 3.78 68.7 8.3
32 170 3.17 66.9 6.9
33 176 4.3 69.2 9.4
34 169 4.2 66.5 9.2
35 169 2.95 66.5 6.5
36 190 5.04 74.8 11.1
37 183 4.73 72.0 10.4
38 173 3.46 68.1 7.6
39 167 3.83 65.7 8.4
40 187 4.73 73.6 10.4
41 180.5 3.79 71.0 8.3
42 180.5 4.64 71.0 10.2
43 150 2.93 59.0 6.4
44 164.5 3.67 64.7 8.0
45 171 3.39 67.3 7.4
46 171.5 3.55 67.5 7.8
47 167.5 3.45 65.9 7.6
48 175.5 3.85 69.0 8.4
49 171 3.51 67.3 7.7
50 175.5 3.57 69.0 7.8
51 160 2.96 62.9 6.5
52 168.5 3.2 66.3 7.0
53 168.5 3.52 66.3 7.7
54 159.5 3.32 62.7 7.3
55 151 2.96 59.4 6.5
56 149 2.89 58.6 6.3
57 150.5 3.1 59.2 6.8
58 174.5 3.55 68.7 7.8
59 155.5 3.06 61.2 6.7
60 155.5 3.21 61.2 7.0
61 161 3.07 63.3 6.7
62 157 3.18 61.8 7.0
63 144.5 3.18 56.8 7.0
64 159.5 3.14 62.7 6.9
65 177 2.7 69.6 5.9
66 185 1.72 72.8 3.8
67 160 1.71 62.9 3.7
68 159 1.52 62.5 3.3
69 158.5 1.56 62.4 3.4



Stats Length in cm Weight in kg Length in inches Weight in pounds
Min. 144.5 1.52 56.9 3.3
Max. 199 5.92 78.3 13.0
Average 170.6 3.5 67.1 7.8
Mode 169 3.51 66.5 7.7



Conclusion

A sword`s weight cannot be judged just from its size or blade width. Hilt style and blade cross-section are determining factors in a weapon`s mass. Just because a blade is thinner does not mean it is necessarily lighter. For example, an Italian side-sword from circa 1550-1560 of 43.5 inches length weighs in at only 2 pounds 6 ounces, while a typical rapier that is much more slender bladed from the same era but just a few inches longer, weighs 2 pounds 9 ounces and still another only 5 inches longer at 3 pounds 3 ounces.From the late 1400s, a large double-handed Kriegsmesserr (or "war knife") of 49.5 inches length is listed as weighing only 3.8 pounds (see the Metropolitan`s 1982, Art of Chivalry, p. 90 & 93-94 for samples).

One historian states, "The true two-handers really did require two hands, though their overall weight averaged only about 8 to 10 pounds. With blades of up to 45 inches or more, the hilts had to be at least 9 inches to counterbalance such a long blade. The crossguard`s length also helped in distributing weight." (William J. McPeak. "For a Swordsmen with Muscle as Well as Skill, Two Hands Could be Better Than One". Military History, Oct 2001, Vol. 18. Issue 4, p 24).

Despite the facts above, many are convinced today that these large swords simply are, or even have to be, exceptionally heavy. The view is not one limited to modern times. For example, Thomas Page`s otherwise unremarkable 1746 military fencing booklet, The Use of the poad Sword, exclaimed nonsense about earlier swords that became largely accepted as fact in the 19th (and 20th) century. Revealing something of how much things in that period had changed from earlier skills and knowledge of martial fencing, declared how their: "Form was rude, and their use without Method. They were the Instruments of Strength, not the Weapons of Art. The Sword was enormous length and peadth, heavy and unwieldy, design`d only for right down chopping by the Force of a strong Arm." (Page, p. A3). Page`s views were not uncommon among fencers then used to featherweight smallswords and the occasional saber and short cutlass.

European sword making technologies throughout the Middle Ages and Renaissance were quite capable of producing high-quality, lightweight, and flexible steel blades for cutting swords that could hold keen edges. These weapons were not intended to defeat heavy plate armor with powerful cuts but did evolve from those longswords that were developed for use against armors by thrusting rather than cutting. Handling real specimens of some of these enormous but beautiful weapons [such as seen in the three images to the right] is enlightening, for their size betrays their exceptional balance. It very quickly becomes clear they were intended for large fighting men to deliver not only powerful slashing blows but great stabbing attacks as well as pole-weapon-like techniques. Large as they were, they were not ridiculously heavy.

For more than a century two-handed greatswords were used less for fighting against armors and more for open battlefield where pike and halberd formations were combined with firearms. Accordingly, just as with its shorter single-hand cousins, the late 15th and early 16th century two-handed greatsword was not a crude excessively heavy bludgeoning weapon but a fairly agile and balanced weapon designed for close-combat in war and occasional duel.

Appreciation to Grzegorz Zabinski for sharing additional data and Stewart Feil for editing assistance. All quotes here are provided by permission of the sources.
